Advanced UPS Runtime Calculator

Enter measured load and the real battery-bank layout. The model accounts for chemistry, discharge rate, reserve, temperature, health and inverter efficiency.

Advanced battery model

Estimate UPS runtime and required battery capacity

Model the battery bank, connected load, efficiency, reserve, temperature and battery health. Results are a planning range, not a guarantee.

Calculated locally in your browser

Quick presets

Connected load and UPS

Connected load W Use a wall-meter reading when possible. UPS rating VA Nameplate apparent-power limit. UPS watt limit W Use the manufacturer watt rating, not VA. Load power factor PF Modern PC supplies are often 0.90–0.99.

Battery bank

Battery chemistry Voltage per battery V Capacity per battery Ah Batteries in series × Parallel strings × Battery health %

Advanced assumptions and reverse sizing

UPS efficiency % Reserve margin % Battery temperature °C Peukert exponent k Ah rating period h Desired runtime min

Planning estimate

UPS runtime result

Enter your system details

Estimated runtime — —

The calculator will show a conservative range after accounting for discharge rate and battery condition.

Battery bank—

Nominal energy—

Usable energy—

Estimated load—

UPS load—

Ah for desired runtime—

Runtime across common load levels

Load	Watts	Estimated runtime

What this result includes

The estimate models bank voltage and Ah, inverter loss, reserve, temperature, battery health and Peukert discharge behavior. Manufacturer runtime curves remain the best final reference.

Rate Advanced UPS Runtime Calculator: 5.0 (1 rating)

Popular tools

All tools

3.0 (2) Utility QR Code Reader Upload an image containing a QR code and decode it in your browser Open tool

3.7 (9) Utility Vibration Test Phone haptics patterns (Vibration API) and gamepad rumble per-motor intensity in one tool Open tool

3.5 (2) Gaming Crosshair Generator Design a custom crosshair with live preview, PNG export, CS2 console command, and Valorant settings values Open tool

2.7 (21) Keyboard Latency Checker Test device and input latency in your browser Open tool

Advanced UPS Runtime Calculator is a free, browser-based online utility that lets you estimate UPS battery backup time with load watts, VA, power factor, battery chemistry, series and parallel banks, Peukert effect, health and temperature.

Cost: Free, no signup
Install: None — runs in the browser
Privacy: Runs locally, no uploads
Platforms: Windows, macOS, Linux, Android, iOS
Time: Under a minute

Reliable planning workflow

How to estimate UPS battery backup time

Runtime is not simply watt-hours divided by watts. High discharge current, battery age, temperature and the UPS inverter all reduce usable energy.

01 Measure the real load Use a wall power meter and enter watts plus the load power factor instead of adding nameplate maximums.

02 Describe the battery bank Enter voltage and Ah per battery, batteries in series, parallel strings, chemistry and estimated health.

03 Review both limits A UPS must have enough watt capacity and enough VA capacity. The stricter percentage sets the headroom verdict.

04 Validate before relying on it Compare the range with the manufacturer curve, then run a controlled self-test with safe shutdown configured.

UPS runtime calculator battery backup time UPS load calculator battery Ah sizing Peukert effect series and parallel batteries

Planning estimate only. Battery manufacturing variation, UPS firmware, waveform, cut-off voltage and sudden load changes can move actual runtime outside the range.

UPS calculator FAQ

UPS runtime calculation questions

How is UPS runtime calculated?

The calculator derives bank voltage and Ah from the series and parallel layout, estimates DC current, then applies inverter efficiency, reserve, health, temperature, chemistry depth of discharge and Peukert discharge behavior.

Why is VA different from watts?

Watts measure real power while VA measures apparent power. A load can remain below the UPS watt rating but exceed its VA rating when power factor is low, so both limits matter.

What is the Peukert effect?

Lead-acid batteries deliver less usable capacity when discharged faster than their rated test rate. A higher Peukert exponent produces a larger high-current penalty. Lithium batteries usually have a smaller effect.

How do series and parallel batteries change capacity?

Series batteries add voltage while Ah stays the same. Parallel strings add Ah while voltage stays the same. The calculator models both dimensions separately.

Can this calculator replace a manufacturer runtime chart?

No. It provides a transparent planning range and overload check. The exact UPS model runtime chart and a controlled battery test are the final references.
